LAMPIZATOR
211 BAL Mono 單聲道後級
TECHNICAL HIGHLIGHTS
- Tube based PSU for small tube section
- Only XLR input
- Stepped resistor ladder volume control with superb precision
- Manual bias with meter
- One triode input stage and one driver stage (White)
- Hand made, point to point wiring
- No interstage transformers
- Silver wires in teflon used for all signal path
- Chokes in PSU and all transformers are custom made in Poland
SPECIFICATIONS :
- Amplifier type : Balanced - single ended triodes in differential scheme
- Power tubes : Directly heated 211 triode pair per channel
- Output : Ultra thin laminated steel symmetrical push pull transformer, 4 & 8 ohm
- Input topology : Single ended noval triode input, symmetrical XLR ture balanced
- Driver : White follower super low impedance driver 6H6P in ture balanced mode
- Signal input : XLR balanced input, monophonic per mono-block
- Volume control : Resistor ladder logarythmic 24 step dual mono true balanced, <1% tolerance
- Adjustements : De-humming cathode pot for 211 Bias Volume
- Bias : Manual bias with negative voltage potentiometer and analog current meter
- Tube compliment : Each amp has : 2 x 211 triodes, 2 x 6H6P dual triodes, E88CC input dual triode, Rectifier diode 5R4 (for samll tubes power)
- Speaker compliment : 4 & 8 ohm, 16 ohm by request
- Output power : 60 Watts @ 8 ohm
- Power consumption : 195W per block
- Front panel colors : Silver or Anodized black
- Size : 43cm[W] x 13cm[H] (plus tubes 20cm) x 52cm[D]
- Weight [per block] : 25kg net, 38kg gross
- Warranty : 5 years (excluding tubes)
REVIEWS :
DOCUMENT DOWNLOAD
211 Bal Mono-datasheet
