KINKI STUDIO
EX-M1+ 合併式擴音機

EX-M1+ (Deluxe Edition)



The EX-M1+ is positioned above the award-winning EX-M1. It is the new flagship model in the Integrated Amplifier lineup of KINKI STUDIO. It packed with most frequently asked features like dimmable display, preamp output, home theater bypass.



Price: HKD 18,800.00 /pc (Silver 銀色)

           HKD 19,800.00 /pc (Black 色)



View All KINKI STUDIO Products

TECHNICAL SPECIFICATION



Parameters

  • Frequency Response: 10-150kHz (±3dB)
  • THDN: 0.0232%; 0.006% (A-Weighted)
  • S/N Ratio: >103dB
  • Output Power: 215W (8Ω), 400W (4Ω), Both channel driven
  • Damping Factor: 2000
  • Gain: Normal Gain 26 dB
  • Max Output Voltage: 55VAC
  • AC Power: 110/240VAC, 50/60Hz (Factory configure)



Input / Output

  • Input Sensitivity: 2.25Vrms - 3.6Vrms
  • Input Impedance: 50kΩ
  • Input Connector: RCA x 3, XLR x 1, HT BYPASS x 1
  • Output: Speaker Binding Post 4mm L/R Channel
  • Output: Preamp Output x 1



Dimension & Weight

  • Dimension: 430W x 125H x 370D
  • Weight: 25KG
DOCUMENT DOWNLOAD
EX-M1+ Instruction Manual
